KCT 2 Roller conveyors are manufactured in standard 2400mm Long sections.

Conveyor sections up to 2400mm can be manufactured to suit alternative section sizes i.e 2 x 1500mm Long sections to provide a 3000mm section.

Minimum width 100mm roller / Maximum Width 600mm roller

Inside Frame Width* = Roller Length (RL) + 10mm

Total Frame widths** = Roller Length (RL) + 90mm

*We are not restricted by standard roller widths, all tracks are made to order. Please specify required roller widths at the time of quotation.

**Custom frame profiles can be manufactured to decrease the tracks overall width.

Standard Roller Centres (mm) : 32, 35, 40, 45, 50, 60

Conveyor pitch or roller centers are the distances between roller centers.

Roller centers must be equally divisible by the length of the conveyor.

Example:

2400mm L Section @ 35mm Pitch = 2,380mm Frame length / 68 Rollers total

Blue 30mm diameter rollers complete with 1.8mm tube walls.

Roller positions are set 5mm below the frame line.

PVC Rollers use FDA approved plastics, incorporating push-fit nylon housed stainless steel ball bearings with 6mm spring axis.

Load ratings per roller up to 10kgs - See table above for individual roller ratings.

PLEASE NOTE: Product weight should not exceed the weight capacity for the rollers. Furthermore, 30mm diameter PVC roller conveyors have a weight capacity of 10 kgs per roller at 100mm width. As a rule with every additional 100mm increment, the load capacity will decrease by 10%

Roller conveyor frames are manufactured using 2.5mm CR4 Grade mild steel.

The KCT 2 conveyor roller frame can be supplied in one of 3 standard colours, RAL5002 Ultramarine Blue, RAL 9010 Pure White, RAL 9005 Jet Black. In addition to the standard colour range, custom powder coated colours are available, together with 304 stainless conveyor roller frames, for example, can be manufactured for food conveyor applications.

Corporate and/or custom colours available on request. (Additional charges may apply)
